Fluidtecq Auto Drain Valves are most economical, simple & maintenance free systems. The compressed air / gas contains Inherent moisture which will condense in receiver tanks, filters and pipelines, which requires regular draining systems -

Fluidtecq Auto drains are the best Solution! Available in wide range of port connection from 1/2" to 2". Coil voltage 12V / 24V / 110V / 220V / 230V AC and DC. With an arrangement of on-time & off time variable settings in secs & mins from 1-99, it provides an effective solution for condensate draining saving loss of maintenance hours and the costly equipment.

Auto drain valve is mainly used for compressors, air dryers etc for draining the moisture condensates.

Digital timer with variable on & off timer settings will be saving manpower, electricity and can save this equipment from condensate problems, helps maintenance people free for other development activities.

ON Time: 1 – 99 secs

Off Time: 1 - 99 Mins ( variable)

Regular discharge models are available in ½” & 1” Sizes

MOC: Aluminum/ SS/ Brass

High discharge models are available from ½” to 3” (external air supply of 3 bar required to operate valve)

Draining condensate, Dryers, Receivers, Filters, For compressors, After coolers, Heat exchangers.

• Sleek Design
• Electronic Display Timer operated drain
• Drain time and OFF time settings in sec/min/hrs
• Transformer prevents damage against voltage fluctuations
• In built strainer for In situ maintenance
• Flameproof Auto Drains certified by CIMFR
• Screwed ends/ Flanged ends connection
• Available in Aluminium (anodized), SS304, SS316
• Nitrile seals/ (Viton for high temperature)
• Pressure upto 70 bar
• High discharge Pilot operated valves

Flame Proof available now.
